ASTM B386 / B386m TZM Titanium Molybdenum Sheet With Good Welding Performance
ASTM B386 / B386m TZM Titanium Molybdenum Sheet With Good Welding Performance ASTM B386 / B386m TZM Titanium Molybdenum Sheet With Good Welding Performance ASTM B386 / B386m TZM Titanium Molybdenum Sheet With Good Welding Performance ASTM B386 / B386m TZM Titanium Molybdenum Sheet With Good Welding Performance

ASTM B386 / B386m TZM Titanium Molybdenum Sheet With Good Welding Performance

Product Details:
Place of Origin: China
Brand Name: JINXING
Certification: ISO 9001
Model Number: TZM Molybdenum Alloy Sheet
Payment & Shipping Terms:
Minimum Order Quantity: 5KGS
Price: 40~100USD/kg
Packaging Details: Plywood case
Delivery Time: 25 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 10000kgs/M
Contact Now

Detail Information
Material: TZM Molybdenum Alloy Standard: ASTM B386 Type 364
Surface: Black, Alkali Cleaning, Grind Type: Molybdenum Alloy 364
Composition: Mo-±0.08% Zr, ±0.5% Ti, ±0.03% C Density: 10.22g/cm3
Working Temperature: 700~1400C Thickness: 0.1mm Min
High Light:

TZM Titanium Molybdenum Sheet

,

B386m Titanium Molybdenum Sheet

,

ASTM B386 Titanium Molybdenum Sheet

Product Description

TZM Molybdenum Alloy Sheet ASTM B386 / B386M , Molybdenum Alloy 364

Molybdenum TZM is an alloy of 0.50% Titanium, 0.08% Zirconium and 0.02% ...

Recrystalization Temp. C. 1400. SPECIFICATIONS. ASTM. B386 type 364.



  • Description

Titanium-Zirconium-Molybdenum Alloy TZM Alloy

TZM Molybdenum alloy sheet has a higher recrystallization temperature, higher strength, hardness at room and elevated temperatures than pure Molybdenum. TZM Alloy offers twice the strength of pure molybdenum at temperatures over 1300 °C. The recrystallization temperature of TZM Alloy is approximately 250 °C higher than molybdenum and it offers better weld ability. For high strength applications such as rocket nozzles, furnace structural components, and forging dies, it can be well worth the cost differential.



TZM Molybdenum alloy sheet advantages compared to pure molybdenum

  • Better creep resistance
  • Higher recrystallization temperature
  • Better high temperature strength
  • Good welding performance


Content(Wt)		 Type Mo purity Single element Other elements
Mo1 ≥99.95% ≤0.01% ≤0.05%
TZM ≥99.95% ≤0.01% ≤0.05%
MHC ≥99.95% ≤0.01% ≤0.05%
M-La ≥99.95% ≤0.01% ≤0.05%



Application field

  • Component isostatic pressing, sintering and heat treatment furnace
  • Metal medical diagnostic rotating anode
  • Ship annealing and sintering process (temperature up to 1400C)
  • Such as injection molding hot runner nozzle forming tools
  • Mold light alloy casting
  • Isothermal forging of billets



ASTM B386 / B386m TZM Titanium Molybdenum Sheet With Good Welding Performance 0
