WNiFe Tungsten Heavy Alloy Aviation Rod
|
Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | JINXING |
| Certification: | ISO 9001 |
| Model Number: | Tungsten Heavy Alloy |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1kg |
| Packaging Details: | Plywood Case |
| Delivery Time: | 10~25 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 10000kgs/M |
|
Detail Information |
|||
| Material: | Tungsten HD Alloy WNiFe / WNiCu | Surface: | Bright Ground Finished |
|---|---|---|---|
| Standard: | ASTM B777 , AMS-T-21014 | Density: | 17~18.5 G/cm3 |
| Dimensions: | Customized | Application: | Aerospace, Military, Medical |
| Highlight: | ASTM B777 Tungsten Heavy Rod,WNiCu Tungsten Nickel Iron Rod,900MPa Tungsten Heavy Rod |
||
Product Description
Tungsten Nickel Iron Alloy Tungsten Heavy Alloy Rod for Sale
Tungsten Alloy metals are mainly including W-Ni-Fe and W-Ni-Cu, are extensively used in military equipment, mechanical manufacturing, aircraft components, medical shields and sports equipment. WNiFe/WNiCu tungsten heavy tungsten heavy alloy WNiFe tungsten nickel ferro/iron alloy.
W-Ni-Fe alloy is used in collimator and shielding components to provide protection against X-ray and γ-ray radiation. A product manufactured from tungsten, nickel and copper, is distinctive due to its non-magnetic behavior. This material is used in the places to avoid magnetic interference.
Specification
| Name | Tungsten Nickel Iron Rod | ||||||
| Grade | AMS-T-21014 | ||||||
| Class 1 | Class 1 | Class 2 | Class 2 | Class 3 | Class 3 | Class 4 | |
| Composition | 90W7Ni3Fe | 91W6Ni3Fe | 92W5Ni3Fe | 93W4Ni3Fe | 95W3Ni2Fe | 96W3Ni1Fe | 97W2Ni1Fe |
| Density (g/cm3) | 17.1±0.15 | 17.25±0.15 | 17.50±0.15 | 17.60±0.15 | 18.10±0.15 | 18.30±0.15 | 18.50±0.15 |
| Heat Treatment | Sintering | Sintering | Sintering | Sintering | Sintering | Sintering | Sintering |
| Tensile Strength (MPa) |
900-1000 | 900-1000 | 900-1100 | 900-1100 | 920-1100 | 920-1100 | 920-1100 |
| Elongation (%) | 18-29 | 17-27 | 16-26 | 16-24 | 10-22 | 8-22 | 6-13 |
| Hardness (HRC) | 24-28 | 25-29 | 25-29 | 26-30 | 27-32 | 28-34 | 28-36 |
| Feature | 1) High resistance to radiation 2) Heavy Density, high ultimate tensile strength, High elastic modulus, and high temperature resistance. 3) Weldability and oxidation resistance greatly enhanced. 4) no harm to environment and health. |
||||||
Applications
*Balancing weights hot rolled Tungsten Heavy Nickel Iron Alloy bar
*The war industry with the ball core,the ball link.the shrapnel,the armor-piercing shell uses the ball
*Substitutional material for Uranium
*Electroheat upsetting anvil block
