90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing
90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing
90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing 90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing 90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing 90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing 90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing

90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing

Product Details:
Place of Origin: CHINA
Brand Name: JINXING
Certification: ISO 9001
Model Number: Best Tungsten Weights For Fishing Slotted Tungsten Heavy Weight For Fishing
Payment & Shipping Terms:
Minimum Order Quantity: 10 kg
Price: Negotiable
Packaging Details: plywood cases
Delivery Time: 15-20 days
Payment Terms: L/C, T/T, D/P, Western Union
Supply Ability: 2000 kg per month
Contact Now

Detail Information
Product Name: Best Tungsten Weights For Fishing Slotted Tungsten Heavy Weight For Fishing Type: 90WNiFe
Density: 16.2 -18.5 G/cc Purity: 90% W
Tensile Strength: 720-1400 MPa Elongation: <10%
Standard: ASTM B777-2009 Applications: Fishing Weight
High Light:

90WNiFe Tungsten Heavy Alloy Weights

,

90WNiFe Tungsten Weights For Fishing

,

ASTM Tungsten Weights For Fishing

Product Description

Best Tungsten Weights For Fishing Slotted Tungsten Heavy Weight For Fishing

Best Tungsten Weights For Fishing are kind of tungsten heavy alloys because they weigh more than twice as much as iron or steel. High specific gravity tungsten alloys are usually refractory metals with two-phase complexes consisting of W-Ni-Fe or W-Ni-Cu or even W-Ni-Cu-Fe. Some tungsten alloys have rare earth and/or other metals such as cobalt, molybdenum and chromium added. Tungsten heavy alloys have a very high melting point, twice the density of steel and more than 50% heavier than lead.

Best Tungsten Weights For Fishing picture:

90WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing 090WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing 190WNiFe Tungsten Heavy Alloy Tungsten Weights For Fishing 2

SPECIFICATION & CHEMICAL COMPOSITIONS  (NOMINALS)

Chemical Composition 90%W 93%W 95%W 97%W
State Sinter Vacuum Forge Sinter Vacuum Forge Sinter Vacuum Sinter Vacuum
Density
(g/cc)		 16.85-17.25 17.15-17.85 17.75-18.35 18.25- 18.85
Hardness
(HRC)		 32 Max 30 Max 40 Min 33 Max 31 Max 40 Min 34 Max 32 Max 35 Max 33 Max
Tensile Strength (Max) 770 Min 900 Min 1400
Max		 770 Min 910 Min 1440 Max 735 Min 920 Min 700 Min 850 Min
Yield Strength
(Mpa)		 620 Min 620 Min 1280 Max 650 Min 650 Min 1340 Max 650 Min 650 Min - -
Elongation
(%)		 5 Min 15 Min 5 Min 5 Min 12 Min 3 Min 3 Min 12 Min 2 Min 6 Min



What is Best Tungsten Weights For Fishing?

Heavy tungsten alloys are mainly divided into two series: W-Ni-Fe and W-Ni-Cu, and even W-Ni-Fe-Cu. In contrast, the W-Ni-Fe alloy has better mechanical properties and plays a huge role in the defense industry and various fields of the national economy. It is a very important new military material in the national defense industry and has been gradually extended to various civilian industries.



Tungsten heavy alloys contain between 90% and 98% tungsten, which is the reason for their high density (16.5 to 19.00 g/cc). Nickel, iron and/or copper are used as a metal binder matrix to hold the fragile tungsten particles together, making the tungsten alloy ductile and easy to process. Nickel-iron is the most commonly used additive in a ratio of 7Ni:3Fe or 8Ni:2Fe (by weight).



Application of Tungsten Heavy Weight

Tungsten alloy fishing tackle pendant is a kind of fishing gear produced with tungsten alloy material. Tungsten alloy fishing pendants have high density, small size and various shapes, and are suitable for various river sections. Tungsten alloy fishing pendants embody the advantages that are different from other manufacturing materials.



  • High density: The density of tungsten alloy can reach 18.5g/cm3, and the volume is much smaller than other materials of the same quality.
  • Corrosion resistance: The chemical properties of tungsten alloy are stable and do not react with any substances at room temperature. Fishing pendants are made of iron, which is easily oxidized if exposed to water for a long time.
  • High hardness: The hardness of tungsten alloy is second only to diamond. It is difficult to avoid collision with hard objects during use. The high hardness material will make the fishing pendant not easy to break and deform.
