WNiFe Military Tungsten Counterweight High Specific Gravity

Product Details:
Place of Origin: CHINA
Brand Name: JINXING
Certification: ISO 9001
Model Number: Military Tungsten Alloy Counterweight
Payment & Shipping Terms:
Minimum Order Quantity: 10 kg
Price: Negotiable
Packaging Details: plywood cases
Delivery Time: 15-20 days
Payment Terms: L/C, T/T, D/P, Western Union
Supply Ability: 2000 kg per month

Detail Information

Product Name: Military Tungsten Alloy Counterweight Grade: WNiFe
Density: 16.3 -18.5 G/cc Purity: W>=93%
Tensile Strength: 730-1400 MPa Elongation: <10%
Standard: ASTM B777-2009 Application: Balance Weight
High Light:

Military Tungsten Counterweight


WNiFe Tungsten Counterweight


93% Tungsten Counterweight

Product Description

Military Tungsten Alloy Counterweight

Military Tungsten Alloy Counterweight is usually composed of tungsten nickel iron, tungsten nickel copper and even tungsten nickel copper iron. Some tungsten alloys also add cobalt, molybdenum, cadmium and other metal elements. It can be made into any shape. High specific gravity tungsten alloy tubes are often used for nuclear shielding and counterweight of military products, such as shotgun, hunting gear, missile, armor piercing projectile, oil drill bit, etc.


Density of Military Tungsten Alloy Counterweight

Chemical Composition 90%W 93%W 95%W 97%W
16.85-17.25 17.15-17.85 17.75-18.35 18.25- 18.85


What is Military Tungsten Alloy Counterweight?

  1. The high density (16.5 ~ 19.00g/cc) is attributed to the tungsten content in heavy tungsten alloy between 90% and 98%. Nickel, iron and / or copper are used as metal binder base materials to fix fragile tungsten particles together, making tungsten alloys plastic and easy to process. Ferronickel is the most commonly used additive, and its ratio is 7Ni: 3Fe or 8ni: 2Fe (weight ratio).

  2. Tungsten alloy tube has high density (60% higher than lead), good mechanical strength, low thermal expansion, good corrosion resistance, high radiation absorption capacity (higher than lead), simple economic cycle, high strength and high specific gravity. It is a suitable material for manufacturing radiation shielding parts. The high density tungsten alloy tube provides the same radiation shielding capacity as lead, while reducing the volume and thickness of the shielding container. Compared with lead and depleted uranium, tungsten alloy also has the advantages of non-toxic and pollution-free. High specific gravity tungsten alloy tubes are mainly used to shield medicine bottles and syringes.

Military Tungsten Alloy Counterweight Picture:
WNiFe Military Tungsten Counterweight High Specific Gravity 0WNiFe Military Tungsten Counterweight High Specific Gravity 1WNiFe Military Tungsten Counterweight High Specific Gravity 2

Application of Tungsten Heavy Alloy Counterweight

  • In addition, due to the special properties of high density, high impact resistance and crack resistance, high specific gravity tungsten alloy is used as counterweight in oil drilling.
