Bright Surface Ni Based Alloys , Easy Processing Alloy 42 Bar 30% Min Elongation

Product Details:
Place of Origin: China
Brand Name: JINXING
Certification: ISO 9001
Model Number: Alloy 42 Rod
Payment & Shipping Terms:
Minimum Order Quantity: 20kg
Price: 15~100USD
Packaging Details: Plywood case
Delivery Time: 15~30days
Payment Terms: L/C, D/P, D/A, T/T, Western Union
Supply Ability: 10000kgs/M

Detail Information

Material: Alloy 42 Hardness HB: ≤130
Yield Strength: 300 Mpa Min Tensile Strength: 500 Mpan Min
Elongation: 30% Min Surface: Bright
High Light:

ni based alloys

,

nickel based superalloys

Product Description

Alloy 42 Rod NILO alloy 42 electrical glass or ceramics NILO 424, Glass Seal 421

Alloy 42 bar belongs to a controlled expansion alloy Similar called: 4J42, Nio 42, NI42 Fe42Ni (UNS K94100 /ASTM F30) (aka Pernifer 402, NILO 424, Glass Seal 421).



Alloy 42 Rod , Alloy 42 Bar



Characteristics: The expansion coefficient is matched with the material to be sealed, and the plasticity is good. Easy to process, no phase change occurs in the working temperature range, good electrical conductivity, thermal conductivity, and high mechanical strength and good processability. The fixed expansion alloys used for sealing include Fe-Ni, Fe-Ni-Co, Fe-Ni-Cr, Ni-Co, as well as oxygen-free copper, tungsten, molybdenum and alloys thereof, composite materials and the like.



Specification range:

Alloy42 plate: thick wall specification (min max): Φ 0.1mm - Φ 200.0mm

Alloy 42 wire: Φ 0.1mm - Φ 3.0mm

Alloy42 straight bar or roll bar: Φ 2.0mm – Φ 300.0mm


For reference.


Alloy42 alloy ║ outer diameter ║ length ║ wall thickness ║ height ║ remarks

Alloy 42 round steel ║ φ 12 - φ 300mm ║ 500-5000mm ║ ║

Alloy42 ring ║ φ 200-1500mm ║ 20-300mm ║ 25-300mm ║

Alloy 42 around disc ║ φ 150-1500mm ║ 5-300mm ║

Alloy 42 raw pipe ║ φ 65-200mm ║ 800-3500mm ║ 7.0-30mm ║ (single support weight not more than 400kg)

Alloy 42 steel pipe ║ φ 65-200mm ║ 1000-9000mm ║ 1.5-25mm ║ (single support weight not more than 350kg)

Alloy 42 hot rolled plate ║ 100-2000 mm ║ 3.5-28 mm ║ width: 100-1000 mm

Alloy42 cold rolled plate ║ 100-2000 mm ║ 0.8-3.2mm ║ width: 100-1000 mm



Heat treatment system of expansion coefficient performance test sample specified in alloy 42 heat treatment system standard: heat the sample to 900 ℃ ± 20 ℃ in hydrogen atmosphere for 1h, and cool it to below 200 ℃ at a speed of no more than 5 ℃ / min [4].







Grade Relative Grade
  Russia U.S.A. U.K.   France Germany
  42 X 6 42Ni-6Cr
Carpenter426
Sylvania4
Sealmet 4
-   ASV(426)
Ni42Cr6
Vacovit426
(NiCr426)
  47 - -   461 -
  49 Carpenter 456 -   FeNi47Cr6 Vacovit 465
Alloy 42 42 Glass Sealing 42
Uniseal 42
Nilo42   N42 Vacodil 42
Nilo42
Alloy 45 46 Niromet 46
Ferrovac 46 Ni
Nilo45   Fe-Ni42 Vacodil 46
Alloy 52 50 FeNi50 Nilo51   N50 Vacovit 500
  52
50-
Glass Sealing 52
Niloy 52
-   N52 Vacovit 520
FeNi52
  - - -   N54 Vacovit 540
FeNi54
