Hastelloy C 276 Reducing Tee Pipe Fitting , Uns N10276 Reducing Branch Tee

Hastelloy C 276 Tee ASME/ANSI B16.9 Equal Tee / Reducer tee EN10204

• Description

Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819

Hastelloy Alloy C-276 Tee Pipe Fittings Specification

Specifications ASTM B366 / ASME SB366

Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79

Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Type Seamless / Welded / Fabricated

Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Grade Hastelloy C276 Pipe Fittings UNS (N10276), DIN (2.4819)

Hastelloy reducing tee is pipe fitting and pipe connector. Also known as pipe tee or tee fitting,

Hastelloy equal tee

Tee joint, used for branch pipe of main pipe.

Three way is a kind of chemical pipe fitting with three ports, namely, one inlet and two outlets; or two inlets and one outlet, which has T shape and Y shape, equal diameter pipe orifice and reducing pipe orifice, and is used for the convergence of three same or different pipes. The main function of tee is to change the direction of fluid.

The mechanical properties of Hastelloy pipe fittings, Hastelloy steel pipes and Hastelloy plate Hastelloy are very outstanding. It has the characteristics of high strength and high toughness, so it has certain difficulties in machining, and its strain hardening tendency is very strong. When the deformation rate reaches 15%, it is about twice that of 18-8 stainless steel. There is also a middle temperature sensitization zone in Hastelloy alloy, and its sensitization tendency increases with the increase of deformation rate. When the temperature is high, the mechanical properties and corrosion resistance of Hastelloy alloy decrease because of its easy absorption of harmful elements. Mechanical properties of materials

1. It can be divided into pushing, pressing, forging, casting, etc.

2. Manufacturing standards can be divided into national standards, electrical standards, ship standards, chemical standards, water standards, American standards, German standards, Japanese standards, Russian standards, etc.

3. According to its curvature radius, it can be divided into long radius elbow and short radius elbow. Long radius elbow refers to the outer diameter of the pipe whose radius of curvature is equal to 1.5 times, that is, r = 1.5D; short radius elbow refers to the outer diameter of the pipe whose radius of curvature is equal to r = 1.0d. (D is the diameter of the elbow, R is the radius of curvature).

4. According to the pressure rating, there are about 17 kinds, which are the same as the American pipe standards, including: sch5s, sch10s, sch10, sch20, sch30, sch40s, STD, sch40, sch60, sch80s, XS; sch80, schh100, sch120, sch140, sch160, XXS; the most commonly used ones are STD and XS.

According to pipe diameter and size

The nozzle ends of equal tee are the same size;

The size of the main pipe of the reducing tee is the same, while the size of the branch pipe is smaller than that of the main pipe.

By process

1. Hydraulic bulging

2. Hot forming
