Zr702 Zirconium Spooled Wire
|
Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | JINXING |
| Certification: | ISO 9001 |
| Model Number: | Zirconium |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 5kgs |
| Price: | 30~150USD/kg |
| Packaging Details: | Plywood case |
| Delivery Time: | 10~25 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 10000kgs/M |
|
Detail Information |
|||
| Material: | Zr 700 , Zr 702 , Zr 704 , Zr 705 | Standard: | ASTM B550 |
|---|---|---|---|
| Process: | Swage Forge, Forge, Hot Rolling | Heat Treatment: | Solution Annealed |
| Surface: | Polished Surface | Density: | 6.51g/cm3 |
| Shape: | Square Bar, Round Bar, Hexagonal Bar, | Size: | Dia.: 3mm - 400mm |
| Highlight: | Chemicals Zr 702 Zirconium Bar,Polished surface Zirconium Bar,Zirconium Bar Solution Annealed |
||
Product Description
JINXING MATECH is committed to the research and development, production and processing of zirconium plates, zirconium pipes, zirconium rods, zirconium rods, zirconium wires, zirconium targets, zirconium flanges, zirconium forgings, zirconium coils, zirconium heat exchangers, zirconium equipment, etc. , International and modern processing equipment.
Zirconium products, such as these rods, have many uses in medical equipment, Zirconium (Zr) 702, 705 UNS R60702 60705 Rod can be made according to standard ASTM B550/B550M-07 . And UNS R60700 rod can be made by ASTM 351;
Process: forging, rolling, lapping, polishing.
| Grade | Element composition (%) < | ||||||||
| Zr+Hf | Hf | Fe+Cr | Sn | H | N | C | Nb | O | |
| R60702 | 99.2 | 4.5 | 0.20 | -- | 0.005 | 0.025 | 0.05 | -- | 0.16 |
| R60704 | 97.5 | 4.5 | 0.20~0.40 | 1.0~2.0 | 0.005 | 0.025 | 0.05 | -- | 0.18 |
| R60705 | 95.5 | 4.5 | 0.2 | -- | 0.005 | 0.025 | 0.05 | 2.0~3.0 | 0.18 |
Mechanical Properties:
R60702 R60705
Tensile strength,min,ksi[Mpa] 55{380}80{550}
Yield strength,min,ksi[Mpa] 30{205}55{390}
Elongation in 2 in.or 50mm,min,%16
Standard:
ASTM B550/B550M-07(2012)
