K30 Tungsten Steel Sheet For Making High Temperature Resistant Parts

Product Details:
Place of Origin: CHINA
Brand Name: JINXING
Certification: ISO 9001
Model Number: K30 Tungsten Steel Sheets
Payment & Shipping Terms:
Minimum Order Quantity: 30 kg
Price: Negotiable
Packaging Details: plywood cases
Delivery Time: 15-20 days
Payment Terms: T/T, L/C, D/P, Western Union, MoneyGram
Supply Ability: 2000 kg per month

Detail Information

Product Name: Tungsten Steel Sheets Type: K30
Density: 14.45 G/cc Standard: ASTM B578-2010
Hardness: 96 HAR Elastic Modulus: 468 GPa
Packaging: Exporting Plywood Cases Application: High-temperature Resistant Parts
High Light:

K30 Tungsten Steel Sheet

,

Temperature Resistant Tungsten Steel Sheet

,

K30 tungsten steel plate

Product Description

K30 Tungsten Steel Sheets For Making High Temperature Resistant Parts

The Tungsten Steel Sheets are mainly made of tungsten carbide, tungsten carbide and cobalt cobalt powder mixed by metallurgical methods such as crushing, ball milling, pressing, and sintering. The main alloy components are WC and Co. The content of WC and Co in tungsten carbide sheets for different purposes is different, and they are widely used. Tungsten steel is one of many materials of tungsten carbide. It is named after its rectangular thin plate (or square), also known as tungsten steel sheets.



Technological Process

Pulverization → formulation according to application requirements → wet grinding → mixing → crushing → drying → screening → adding molding agent → re drying → preparing mixture after screening → granulation → pressing → forming → sintering → forming (blank) → flaw detection → packaging → warehousing

Tungsten Steel Sheets Garde & Technical Parameters

Grade Co% Hardness
HAR
Density
g/cm
Flexural strength
MPa
Elastic modulus
GPa
Thermal expansion coefficient
10/C
Application
JX10 10 91.7 14.4 4300 490 5.4 Copper, aluminum and other thin sheets with thickness less than 0.2mm
JX15 12 92.5 14.1 4500 460 5.8 Copper, aluminum, stainless steel, etc
JX20 13 90.6 14.1 4100 460 5.8 Strong applicability, copper, aluminum and other thin sheets
JX35A 12 89.8 14.2 3400 470 5.7 Q195, SPCC and other cold rolled sheets
JX36 15 89.4 13.8 3900 430 6.3 EI, SPCC and other cold rolled sheets
JX40A 12 88.9 14.2 3300 470 5.7 Q195, SPCC and other cold rolled plates, high-speed stamping dies and multi station progressive dies
JX45A 15 87.9 13.9 3200 440 6.1 Die for silicon steel sheet, cold rolled sheet, hardware and standard parts
JX55 20 86.4 13.5 3100 390 6.8 Silicon steel sheet, upper and lower punches





Application range classification

  • Tungsten steel sheets are suitable for machining at high temperature. It can be used to make cutting tools, structural materials of kilns, jet engines, gas turbines, nozzles, etc. The super coarse tungsten carbide powder raw material for super coarse tungsten carbide co cemented carbide has a series of advantages such as complete crystal structure, few structural defects, high microhardness, small micro strain and certain plasticity. The cemented carbide manufactured with it has good toughness, impact resistance, high high high temperature hardness, high thermal conductivity and small creep deformation. It is widely used in mining tools, oil drilling and production tools Shearer mining tools, shield machine tools for tunnel engineering, stamping dies, composite rollers, hard surface spraying and spray welding of metal surface, etc.

K30 Tungsten Steel Sheet For Making High Temperature Resistant Parts 0K30 Tungsten Steel Sheet For Making High Temperature Resistant Parts 1

Performance characteristics of tungsten steel sheets

Tungsten steel sheets have the characteristics of high hardness, high hardness, good wear resistance, high elastic modulus, high compressive strength, good chemical stability (acid resistance, alkali resistance, high temperature oxidation resistance), low impact toughness, small expansion coefficient, etc., heat conduction The properties and conductivity are similar to iron and its alloys.
