Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar
Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar
Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar

Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar

Product Details:
Place of Origin: China
Brand Name: JX
Certification: ISO
Model Number: Copper Tungsten Electrodes Tungsten Copper Bar Copper Tungsten Bar
Payment & Shipping Terms:
Minimum Order Quantity: 10kgs
Price: according to actual products
Packaging Details: standard packing
Delivery Time: 25days
Payment Terms: T/T
Supply Ability: 300kgs month
Contact Now

Detail Information
Size: As Request Quality: ISO9001:2008
Surface: Polishing,burnishing,black Surface Delivery Time: 25days
Packing: Standard Exporting Name: Copper Tungsten Electrodes Tungsten Copper Bar Copper Tungsten Bar
High Light:

Copper Tungsten Alloy Products

,

Tungsten Alloy Products Electrodes

,

Tungsten Copper Bar Electrodes

Product Description

Copper Tungsten Electrodes Tungsten Copper Bar Copper Tungsten Bar

Tungsten Copper Bar are used where the combination of high heat resistance, high electrical and/or thermal conductivity, and low thermal expansion are needed. Some of the applications are in electric resistance welding, as electrical contacts, and as heat sinks. As contact material the alloy is resistant to erosion by electric arc. WCu alloys are also used in electrodes for electrical discharge machining and electrochemical machining.
Tungsten Copper Bar Picture:

Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar 0Copper Tungsten Alloy Products Electrodes Tungsten Copper Bar 1
We can produce various sizes Tungsten Copper Bar as per customers' request.

Code No. Chemical Composition % Mechanical properties
CU Impurity W Density   RES( cm)
(g/cm 3 ) Hardness Conductivity TRS/ Mpa
  HB IACS/ %

CuW(50) 50 + 2.0 0.5 Balance 11.85 115 3.2 54
CuW(55) 45 + 0.5 Balance 12.3 125 3.5 49
2
CuW(60) 40 + 2.0 0.5 Balance 12.75 140 3.7 47
CuW(65) 35 + 2.0 0.5 Balance 13.3 155 3.9 44
CuW(70) 30 + 2.0 0.5 Balance 13.8 175 4.1 42 790
CuW(75) 25 + 2.0 0.5 Balance 14.5 195 4.5 38 885
CuW(80) 20 + 2.0 0.5 Balance 15.15 220 5 34 980
CuW(85) 15 + 2.0 0.5 Balance 15.9 240 5.7 30 1080
CuW(90) 10 + 2.0 0.5 Balance 16.75 260 6.5 27 1160

If you need this products, please feel free to contact us.




Advantages of Tungsten Copper Bar
1. Better heat resistant;
2. Better ablate-resistant;
3. High intensity
4. High density;
5. Excellent thermal and electrical conductivity;
6. Easyto be machined.

Dimensions of Tungsten Copper Bar


Type Dimension(mm) Note:

W-Cu copper
Length(mm)
Width(mm)
Height(mm)

W50
100-600
10-300
2-200

W55
100-600
10-300
2-200

W60
100-600
10-300
2-200

W65
100-600
10-300
2-200

W70
100-600
10-300
2-200

W75
100-600
10-300
2-200

W80
100-600
10-300
2-200

W85
100-600
10-300
2-200

W90
100-600
10-300
2-200
