Tungsten W Bucking Bars For Riveting
|
Product Details:
|
|
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | JINXING |
| Certification: | ISO 9001 |
| Model Number: | YG10 Tungsten Carbide Cutting Tool |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 30 kg |
| Price: | Negotiable |
| Packaging Details: | plywood cases |
| Delivery Time: | 15-20 days |
| Payment Terms: | T/T, L/C, D/P, Western Union, MoneyGram |
| Supply Ability: | 2000 kg per month |
|
Detail Information |
|||
| Product Name: | YG10 Tungsten Carbide Cutting Tool | Type: | Yg10 |
|---|---|---|---|
| Density: | 14.6 G/cc | Standard: | ASTM B578-2010 |
| Hardness: | 97 HAR | Elastic Modulus: | 465 GPa |
| Packaging: | Export Plywood Cases | Application: | CNC |
| Highlight: | Tungsten Carbide Cutting Tool Inserts,YG10 Tungsten Carbide Cutting Inserts,CNC Machining Tungsten Carbide Cutting Inserts |
||
Product Description
Tungsten Carbide Cutting Tool are mainly composed of tungsten carbide and cobalt powder. They are made by metallurgical mixing, crushing, ball milling, pressing and sintering The alloy is mainly composed of WC and Co, with different contents of WC and Co for different purposes, so it is widely used As it is a rectangular plate (or square plate), it is also called tungsten carbide plate
Pulverizing → Formula according to use requirements → Wet grinding → Mixing → Crushing → Crushing → Drying → Screening → Adding molding agent → Re drying → Blending after screening → Granulating → Forming → Pressing → Forming → Sintering → Forming (blank) → Flaw detection → Packaging → Warehousing
Carbide billet has excellent hardness, high hardness, good wear resistance, high elastic modulus, high compressive strength, chemical stability (acid resistance, alkali resistance, high temperature oxidation resistance), low impact toughness, low expansion coefficient, and heat resistance. Very good features.
Cemented carbide billets are mainly used to manufacture copper, aluminum, stainless steel, cold-rolled plate, EI plate, Q195, SPCC, silicon steel sheet, hardware, standard parts, high-speed lifting die, multi-stage progressive die punch and other plates. It is also the first choice for manufacturing high-temperature parts, wear-resistant parts, shielding parts and corrosion resistant parts.
| Grade | Co% | Hardness HAR |
Density g/cm |
Flexural strength MPa |
Elastic modulus GPa |
Thermal expansion coefficient 10/C |
Application |
| JX10 | 10 | 91.7 | 14.4 | 4300 | 490 | 5.4 | Copper, aluminum and other thin sheets with thickness less than 0.2mm |
| JX15 | 12 | 92.5 | 14.1 | 4500 | 460 | 5.8 | Copper, aluminum, stainless steel, etc |
| JX20 | 13 | 90.6 | 14.1 | 4100 | 460 | 5.8 | Strong applicability, copper, aluminum and other thin sheets |
| JX35A | 12 | 89.8 | 14.2 | 3400 | 470 | 5.7 | Q195, SPCC and other cold rolled sheets |
| JX36 | 15 | 89.4 | 13.8 | 3900 | 430 | 6.3 | EI, SPCC and other cold rolled sheets |
| JX40A | 12 | 88.9 | 14.2 | 3300 | 470 | 5.7 | Q195, SPCC and other cold rolled plates, high-speed stamping dies and multi station progressive dies |
| JX45A | 15 | 87.9 | 13.9 | 3200 | 440 | 6.1 | Die for silicon steel sheet, cold rolled sheet, hardware and standard parts |
| JX55 | 20 | 86.4 | 13.5 | 3100 | 390 | 6.8 | Silicon steel sheet, upper and lower punches |
